TS-1101L is a Bluetooth 5.1 positioning beacon with ultra-long battery life. It adopts imported Bluetooth chip design and has the remarkable characteristics of ultra-low power consumption, long distance and low cost.
TS-1101L battery capacity 2200mAh, using a pair of AAA lithium iron battery, 1S broadcast frequency setting, can be used for 10 years, and the battery is easy to replace, can greatly reduce maintenance costs.
TS-1101L can be fixed by glue or screw, and is widely used in indoor positioning, indoor navigation, exhibition navigation, social check-in, advertising push, asset management, item tracking, patrol clock and other solutions.
| Model No. | TS-1101L |
| Bluetooth Version | Bluetooth 5.1 |
| Chipset | Dialog DA145 Series |
| TX Power | -19.5~+2.5 dBm, Default +2.5dBm |
| OTA | YES |
| Distance | 120m in the open |
| Battery | AAA lithium iron battery * 2 (Replaceable) |
| Battery Life | 8 Years（+2.5dBm/1s） |
| Certification | BQB, FCC, CE, SRRC, RoHS, REACH |
| Color | White |
| Weight | 35g (including Battery) |
| Size | Φ62.2*17.3mm |
| OEM | Custom color, Print Logo, OEM Package, Software |
